56 PNEG-225 Corrugated Floor and Monorail Layouts
5. Layouts
48' Bin Floor Layouts (Continued)
48' Diameter Monorail Lengths
Monorail Number Sec 1 Sec 2 Sec 3
1 149 264 149
2 148 264 148
3 148 264 148
4 147 264 147
5 145 264 145
6 143 264 143
7 141 264 141
8 138 264 138
9 135 264 135
10 132 264 132
11 128 264 128
12 124 264 124
13 119 264 119
14 114 264 114
15 108 264 108
16 101 264 101
17 94 264 94
18 87 264 87
19 78 264 78
20 69 264 69
21 59 264 59
22 47 264 47
23 166 166 -
24 152 152 -
25 135 135 -
26 231 - -
27 180 - -
28 104 - -
29 36 - -
