44 PNEG-225 Corrugated Floor and Monorail Layouts
5. Layouts
39' Bin Floor Layouts (Continued)
39' Diameter Monorail Lengths
Monorail Number Sec 1 Sec 2 Sec 3
1 95 264 95
2 94 264 94
3 94 264 94
4 92 264 92
5 90 264 90
6 88 264 88
7 85 264 85
8 82 264 82
9 78 264 78
10 74 264 74
11 69 264 69
12 63 264 63
13 57 264 57
14 50 264 50
15 42 264 42
16 165 165 -
17 155 155 -
18 143 143 -
19 260 - -
20 229 - -
21 190 - -
22 139 - -
23 42 - -
24 36 - -
