40 PNEG-225 Corrugated Floor and Monorail Layouts
5. Layouts
36' Bin Floor Layouts
36' Diameter Monorail Lengths
Monorail Number Sec 1 Sec 2 Sec 3
1 77 264 77
2 76 264 76
3 75 264 75
4 74 264 74
5 72 264 72
6 69 264 69
7 66 264 66
8 63 264 63
9 58 264 58
10 54 264 54
11 48 264 48
12 42 264 42
13 167 167 -
14 159 159 -
15 149 149 -
16 139 139 -
17 254 - -
18 225 - -
19 191 - -
20 145 - -
21 71 - -
22 36 - -
