36

PNEG-225 Corrugated Floor and Monorail Layouts

5. Layouts

30' Bin Floor Layouts

Figure 5Q

30' Diameter Monorail Lengths

Monorail Number

Sec 1

Sec 2

Monorail Number

Sec 1

Sec 2

1

172

172

10

144

144

2

172

172

11

137

137

3

170

170

12

257

-

4

168

168

13

237

-

5

167

167

14

214

-

6

164

164

15

186

-

7

160

160

16

150

-

8

155

155

17

98

-

9

150

150

18

36

-
