50 PNEG-225 Corrugated Floor and Monorail Layouts
5. Layouts
42' Bin Floor Layouts (Continued)
42' Diameter Monorail Lengths
Monorail Number Sec 1 Sec 2 Sec 3
1 101 264 101
2 100 264 100
3 100 264 100
4 98 264 98
5 96 264 96
6 94 264 94
7 91 264 91
8 88 264 88
9 84 264 84
10 80 264 80
11 75 264 75
12 70 264 70
13 64 264 64
14 57 264 57
15 49 264 49
16 41 264 41
17 163 163 -
18 152 152 -
19 140 140 -
20 252 - -
21 217 - -
22 174 - -
23 113 - -
24 36 - -
25 - -
