| 25
Wire Color Color Code
BrOWN with WhItE stripe Br/Wt
Dark GrEEN with yELLOW stripe DG/yL
LIGht GrEEN with BLaCk stripe LB/Bk
PINk with Gray stripe Pk/Gy
rED rD
taN with BLaCk stripe tN/Bk
VIOLEt with OraNGE stripe Vt/Or
VIOLEt with yELLOW stripe Vt/yL
WhItE Wt
WhItE with Dark GrEEN stripe Wt/DG
WhItE with OraNGE stripe Wt/Or
yELLOW yL
yELLOW with OraNGE stripe yL/Or
yELLOW with rED stripe yL/rD
taBLE Z . Wire colors and the corresponding color codes
2003 2004
NO.
Installation
steps
Banks
Brake Wire
auto trans
(Connector - Wire
Colors)
manual trans
(Connector - Wire
Colors)
auto trans
(Connector - Wire
Colors)
manual trans
(Connector - Wire
Colors)
1 15, 20, 25,30 BLuE
tPs - yL
(Pin #3)
Figure Z1
aPPs - Wt/DG
or Wt (Pin #5)
Figure Z2
aPPs - Br/Wt
(Pin #3)
Figure Z1
aPPs - Br/Wt
(Pin #5)
Figure Z2
2 12, 17, 21, 26 BLaCk
C130* - rD
(Pin #N2)
Figure Z3
C130* - LG/Bk
(Pin #J5)
Figure Z3
C130** (bk) - yL/
Or
(Pin #B1)
Figure Z5
C130** (bk) - Pk/
Gy
(Pin # B4)
Figure Z5
3 18, 28 BrOWN N/a
C130* - yL/rD
(Pin #B2)
Figure Z3
N/a
C131 (gray) - Vt/
yL (Pin # B4)
Figure Z6
4 11, 16, 22, 27 OraNGE
C130* - Wt/Or (Pin #J2)
Figure Z3
CaB C1- DG/yL (Pin # 12)
Figure Z7
5 31 Gray
Cts - tN/Bk (Pin #2)
Figure Z4
Cts - tN/Bk or Vt/Or (Pin #B)
Figure Z4
Wire Connection
reference
Engine Banks Exhaust
Brake
Wire Colors
Voltages Figures
key On/Engine Off BLuE
(Pin # 2)
~0.5V @ no throttle
> 2V @ full throttle
6 or 7
BLaCk
(Pin #6)
Ground N/a
yELLOW
(Pin #11)
11 to 15V
(to fuse)
N/a
rED
(Pin #1)
11 to 15V
(power switch)
N/a
Gray*
(Pin #8)
> 2V (coolant
temperature
is <120 deg F)
10
