34
96834 v.1.0
Section 17
NaVIGaTION MODE
WaRNING! Banks GPS Navigation
is an optional feature available
to purchase from Gale Banks
Engineering. This option is not
standard on Banks iQ and will be
disabled in the Mode Select menu.
The software is sold on a micro SD
card and must be inserted into the
micro SD card port on the Banks
iQ to run the Navigation program.
Once the iQ detects the Navigation
program the option will be made
available for use.
Please contact Banks Sales Department
at (888) 635-4565 to purchase a copy of
Banks GPS Navigation.
Banks GPS Navigation is a voice
guidance program that uses statistical
and probability analysis to help you
select and set destinations quickly
and easily. As you travel, the program
displays your location on the map. Voice
guidance tells you when and where to
turn. See Figure 34. The main screen
displays turn directions, compass
heading, distance to next maneuver, and
street names. If you leave your route, the
program calculates a new route to your
destination automatically.
Please refer to the Banks Navigation
manual for step-by-step instruction of
the navigation program.
-END, SEcTION 17-
Section 16
GPS DaTa MODE
GPS Data
The GPS Data Mode provides the current
status of the GPS in the Banks iQ. In
the Mode selection menu press on the
‘GPS Data’ button. The Data displays
the accuracy of the system depending
on signal, the GPS Time, the Speed the
GPS is traveling, Latitude, Longitude, and
the GPS Elevation. See Figure 33. After
reviewing the data, press the ‘iQ’ icon to
return to the Navigation Mode selection
menu.
-END, SEcTION 16-
Section 15
COMPaSS MODE
Compass
Press on the ‘compass’ button in the
‘Mode Select’ menu. The compass
screen will display four (4) changeable
gauges and a compass. See Figure 32.
Refer to Selection 20 to change the
gauges displayed from a list of available
parameters.
The compass can be adjusted to have
the vehicle pointer in the center spin
around the compass settings or have
the compass spin around the vehicle
pointer to show the current heading. To
adjust the compass method of direction
pointing, press on the ‘Wrench’ icon to
go to the ‘Options’ menu. Press on the
‘Direction’ tab in the ‘Options’ menu. In
the Direction menu press ‘North up’ to
have the vehicle pointer rotate around
the compass or press ‘Direction up’
to have the compass rotate around
the vehicle pointer. After setting the
compass, press the iQ icon to return to
the ‘Mode Select’ menu screen.
-END, SEcTION 15-
