96834 v.1.0
21
Press the ‘Power’ button on the
bottom part of the screen to change
power levels with your Banks Power
Tuner. Press the ‘Brake’ button to
change brake modes, select brake
intensity, and target speed with
your SpeedBrake. This option is only
available if both a Banks Power Tuner
and SpeedBrake are purchased and
installed in your vehicle.
The active devices and settings will be
highlighted in red at the bottom of the
screen. See Figure 16.
On the lower left hand corner of
the screen is the ‘Banks iQ Home’
icon, which will direct you back to
the ‘Mode Select’ menu, and the
‘Wrench’ icon that will direct you to
the ‘Adjustments’ menu. For more
description of the ‘Adjustments’ menu,
please see Section 18 .
-END, SEcTION 8-
Section 8
COMBO POWER & SaFETY SCREEN
Figure 16 Combo Power & Safety Screen
Banks iQ performance testing allows
the user to run a 1 /
8
mile, 1 /
4
mile, or a
0-60 MPH test run.
Setting up for Performance
Testing
1.
Press the ‘Performance’ button
in the ‘Mode Select’ menu. The
Performance Screen will appear. See
Figure 17.
2.
Banks iQ lets you change any of the
gauges on view in the Performance
display. changing the displayed gauges
does not affect the measurements
actually being recorded during the
test. If you would like to change these
gauges, simply press the gauge you
want to change and you will be taken
to the Gauge Placement menu. See
Section 20 .
3.
Select the performance test you want
to run: ‘0-60 MPH’, ‘ 1 /
8
Mile’, ‘ 1 /
4
Mile’.
See Figure 18.
Section 9
PERFORMaNCE MODE
