32
96814 v.2.0
If the Banks EconoMind Diesel Tuner
has been moved to a different
vehicle, or you are instructed to
do so by Banks Technical Staff,
it is possible to reset all of the
parameters that the EconoMind has
‘learned’.
CAuTIoN: The following
procedures can only be carried
out with the engine oFF!
1.
Turn the vehicle key to ON but Do
NoT start the engine.
2.
Fully depress the throttle pedal
and then release it completely.
Repeat 5 times. The GREEN LED
will flash when this is completed
successfully.
3.
Turn the key OFF. Wait 30
seconds, or until the GREEN LED goes
off and stays off. Turn the key back
to the ON position but Do NoT start
the engine.
4.
Fully depress the throttle pedal
and then release it completely.
Repeat 5 times
-END, SEcTION 11-
Section 11
CLEARING LEARNED PARAMETERS
Diagnosing EconoMind error
codes without the Banks iQ.
If you feel that your Banks EconoMind
Diesel Tuner is not functioning properly,
some diagnostics can be performed.
Your EconoMind Diesel Tuner is
equipped with diagnostic features that
will detect and display certain errors.
Remove the Banks EconoMind Diesel
Tuner from its mounting location while
keeping all connectors plugged in,
and position it in such a way that you
can view the end of the EconoMind
housing that contains the LEDs from
the driver’s seat. Turn the vehicle key
to the ON position. Observe the two
LEDs mounted on the end of the Banks
EconoMind Diesel Tuner:
• A steady GREEN LED will illuminate
if all wire connections are correct,
the engine is running, and the engine
coolant temperature is within its
normal operating range.
• The GREEN LED will flash if all wire
connections are correct, the engine
is running, but the engine coolant
temperature is not within its normal
operating range. The GREEN LED will
stop flashing once the engine coolant
temperature is within its normal
operating range.
• No LEDs will illuminate if the fuse
on the EconoMind wiring harness is
blown or the wiring harness is not
properly connected. If the fuse and all
connections are okay, contact Banks
Technical Service.
• The RED LED will flash in a certain
sequence if a connection is incorrect
of if there is a problem with the
system – this sequence will identify
one or more diagnostic codes. A Banks
EconoMind Diesel Tuner’s diagnostic
code is comprised of 2 digits. Each
code is expressed in a sequence of 2
sets of the flashing red LED separated
by a brief flashing of the green LED in
between. Each set of a number of red
LED flashes represents a digit. A longer
flashing of the green LED separates
the sequences. The LEDs will continue
to flash to display all the errors, and
then repeat. Table 1 lists the common
diagnostic codes. For example, if a
faulty thermocouple is detected (code
“2,3”) by the Banks EconoMind Diesel
Tuner, the following red and green LED
flashing sequence is observed when
the key is on:
(1) Two times flashing RED LED
(2) One time quick flashing GREEN LED
(3) Three times flashing RED LED
(4) One time longer flashing GREEN LED
The above flashing sequence will
repeat continuously. When the problem
is corrected, the diagnostic code will
be eliminated and replaced by a steady
green light.
NOTE: If multiple codes are set, they
will be displayed in a series separated
by the longer flashing green LED. When
reading codes, make sure to watch the
entire series until you see the first code
repeat.
-END, SEcTION 10-
