background image

26

96450 v.9.0

DIAGNOSTIC

CODE

CODE DESCRIPTION

COURSE OF ACTION

1,1

Faulty Injection
control Pressure (IcP)
input signal

Check 46-pin connectors. Reset Six-Gun
Diesel Tuner by turning key ON and OFF.

1,2

Faulty Manifold

Absolute Pressure
(MAP) input signal

check MAP sensor connection and 12-pin

Six-Gun Diesel Tuner connector. Reset
Six-Gun Tuner by turning key ON and
OFF.

1,3

Faulty Six-Gun signal
input

Make sure the Six-Gun switch is

connected to the main wire harness.
Reset the Six-Gun Diesel Tuner by turning
the key ON and OFF.

1,4

Faulty barometric
pressure sensor

check barometric T-tap connection

(VIOLET wire). Boost pressure displayed

by the gauges will not be accurate when
changing altitude, but the module will
operate normally.

2,1

Faulty Injection control
Pressure (IcP) output
signal

Check the 46-pin Six-Gun Diesel Tuner
connectors. Reset Six-Gun Diesel Tuner
by turning key ON and OFF.

2,2

Faulty Manifold
Absolute Pressure
(MAP) output signal

check MAP sensor connection and 12-pin

Six-Gun Diesel Tuner connector. Reset
Six-Gun Tuner by turning key ON and
OFF.

2,3

Faulty thermocouple
signal

check thermocouple ring terminal
connections.

2,4

Tcc stuck (automatic
transmission ONLY)

check Tcc T-tap connection (GRAY wire).

Monitor code occurrence. contact Banks
Technical Service if occurrence becomes
frequent.

3,4

Faulty cAN bus signal

Check 46-pin connectors. Reset Six-Gun
Diesel Tuner by turning key ON and OFF.

Table 1: Banks Six-Gun Diagnostic Codes
