Rough Country 1128 - Manual

XJ CHEROKEE FR SWAY BAR DISCONNECT KIT
Thank you for choosing Rough Country for your suspension needs.
Please read all the instructions before beginning the installation. Check the kit hardware against the parts list. Be sure
you have all the needed parts and understand where they go. If you have any questions about the installation of this kit,
call Rough Country at 731-285-9000.
NOTICE TO DEALER AND VECHICLE OWNER
Any vehicle equipped with any Rough country product must have the “Warning to Driver” decal installed on the sun visor
or dash. The decal is to act as a constant reminder for whoever is operating the vehicle of its unique handling character-
istics. INSTALLING DEALER—It is your responsibility to install the warning decal and to forward these installation in-
structions on too the vehicle owner for review and to be kept in the vehicle for its service life.
92112800
Wheel Chocks
T-55 Torque Bit
15mm Socket / Wrench
18mm Socket / Wrench
19mm Socket / Wrench
1/2” Socket / Wrench
9/16” Socket / Wrench
3/4” Socket / Wrench
Drill Motor
Tools Needed:
Torque Specs:
Size Grade 5 Grade 8
3/8” 30 ft/lbs 35 ft/lbs
1/2” 65 ft/lbs 90 ft/lbs
9/16” 95 ft/lbs 130 ft/lbs
INSTALLATION INSTRUCTIONS
1. Remove the sway bar links on both sides using a T-55 torx bit /19mm wrench and a 15mm for the upper nut . See
Photo 1.
2. Install the upper sway bar mount on the top of front sway bar where the stock link was secured, using the supplied
3/8” x 1.25” bolt lock washer and flat washer. Tighten using a 9/16” wrench making sure the mount is straight. See
Photo 2.
PHOTO 1
Remove upper sway bar link from sway bar
PHOTO 2
Install mount on sway bar
