Rough Country 1083 - Manual

97– 06 TJ FRONT ADJ TRACK BAR KIT FOR 0”-3 1/2” LIFT
INSTALLATION INSTRUCTIONS
1. Remove the track rod from the axle and from the frame using a 15mm (axle) & 18mm wrench (frame).
2. Grind the back side of the mount smooth to allow the track rod bracket to be installed. See Photo 1.
3. Install the new track rod bracket on the frame as shown in Photo 2 using the supplied 1/2” x 1 3/4” bolt, washer &
nut in the stock mount. Tighten using a 19mm Socket & wrench. View from the passenger side.
92108300
Thank you for choosing Rough Country for your Jeep off road needs.
Please read all the instructions before beginning the installation.
PRODUCT USE INFORMATION
We will be happy to answer any questions regarding our products by calling us @ 800-222-7023. Rough Country will
not be responsible for any product that is altered. This kit is for use with vehicles lifted 0”- 3” of lift.
KIT CONTENTS
1-TRACK ROD BRACKET
1-ADJ TRACK ROD BODY & END
TOOLS NEEDED
DRILL MOTOR
13/32” DRILL BIT
15MM SOCKET / WRENCH
18MM SOCKET / WRENCH
19MM SOCKET / WRENCH
9/16” SOCKET / WRENCH
1 1/2” WRENCH
PHOTO 1 PHOTO 2
GRIND BRACKET FLAT INSTALL 1/2” X 1 3/4” BOLT , WASHERS NUT
1-POLY BAG CONTAINING:
2-7/16”
SPACERS
1-7/16” X 2 3/4” BOLT
2-7/16” FLAT WASHERS
1-7/16” LOCK NUT
1-1/2” X 1 3/4” BOLT
1-1/2” FLAT WASHER
1-1/2” LOCK NUT
2-BUSHINGS
1-12MM
SLEEVE
1-12MM X 80MM BOLT
1-12MM LOCK NUT
1-3/8” X 2” BOLT
2-3/8” FLAT WASHERS
1-3/8” LOCK NUT
1-3/4” JAM NUT
