THANK YOU FOR CHOOSING ROUGH COUNTRY FOR YOUR SUSPENSION NEEDS
3. Install the new sway bar link on the sway bar bracket and swing up the assembly to the frame rail. See Photo 3. Re-
move the sway bar link from the bracket while holding the bracket in place.
4. Mark the holes to be drilled and remove the bracket from the frame. See Photo 4.
5. Drill the two holes per side using a 17/64” drill bit. See Photo 5. Be sure to only drill through the outside of the frame
rail.
6. Install the frame bracket with the supplied 5/16” self tapping bolts (2 per bracket) using a 1/2” wrench as shown in
Photo 6.
7. Install the supplied mounting pin as shown in Photo 7 and tighten using 19mm socket / wrench.
8. Swing the new sway bar link down and secure on the mounting pin using the supplied quick disconnect pin. See
Photo 8.
POST INSTALLATION INSTRUCTIONS
1. Check all fasteners for proper torque. Check to ensure there is adequate clearance between all rotating, mobile,
fixed and heated members.
2. All components must be retightened after 500 miles, and every three thousand miles after installation.
Photo 3 Photo 4
Photo 5 Photo 6
Position bracket to be drilled Center punch holes
Drill Holes using a 17/64” drill bit Tighten 5/16” self tapping bolts
Install mounting pin on the axle Link shown installed on pin
Photo 7 Photo 8
