Rough Country 1168 - Manual

JEEP JK 2 1/2” - 4” TRACK BAR KIT
Thank you for choosing Rough Country for your suspension needs.
In addition to these instructions, professional knowledge of disassemble/reassembly procedures as well as post installa-
tion checks must be known.
Please read instructions before beginning installation. Check the kit hardware against the
parts list. Be sure you have all needed parts and know where they go. Also please review tools needed list and make
sure you have needed tools. If question exist we will be happy to answer any questions concerning the design, function,
and correct use of our products by calling 1-800-222-7023.
Tools Needed:
21mm Socket / Wrench
INSTALLATION INSTRUCTIONS
POST INSTALLATION
All components must be retightened after 500 miles, and every
three thousand miles after installation.
Thank you for using Rough Country Suspension for your off road needs!!
1. Using a 21mm socket, remove bolt securing the front track bar to the frame. Retain stock hardware. See Photo 1.
2. Remove the track bar from the axle using a 21mm wrench. Retain the hardware for reuse. See Photo 2.
3. Assemble the bushings/sleeves in the track rod and adjust
to a length of 32 7/8” center of hole to center of hole. Install the
new track bar into stock frame bracket using the stock hard-
ware.
4. Check to make sure the body is centered over the axle and
install the lower end of the new track rod on the axle as shown
in Photo 3. Torque all fasteners to specifications. It may be
necessary to turn the steering wheel to align the track rod
end with the axle.
PHOTO 1
Remove the track rod from the frame
PHOTO 2
Remove the track rod from the axle
PHOTO 3
Install the track rod on the axle
Parts Included:
1-Track Bar Body
1-Heim End
1-Jam Nut
2-Heim Spacers
92116800
