Rough Country 87306 - Manual

JEEP JK STABILIZER KIT
KIT CONTENTS:
1- Axle bracket
1-Stabilizer Cylinder TOOLS NEEDED:
18mm Socket / Wrench
21mm Socket / Wrench TORQUE SPECS:
⅜”
30 ft/lbs - 35 ft/lbs
½” 65 ft/lbs - 75 ft/lbs
STABILIZER INSTALLATION INSTRUCTIONS
1. Remove the factory stabilizer from the axle using a 18mm socket. See Photo 1. Retain the factory hardware for
reuse if reusing the factory stabilizer.
2. Remove the factory track bar from the axle mount using a 18mm socket. Retain the factory hardware for reuse.
3. Place the new bracket on the axle mount as shown in Photo 2 and place the track rod in the axle mount and secure
with the factory track rod bolt. Do not tighten at this time.
4. Install the supplied 3/8” x 1 1/4” bolt , flat washer and flange lock nut on the stabilizer bracket as shown in Photo 3
and tighten hardware.
5. Install stabilizer in the mount with the supplied 1/2” x 2 1/2” bolt if using Rough Country stabilizer and if using the
factory stabilizer reuse the factory hardware. See Photo 4.
PHOTO 1 PHOTO 2
PHOTO 3 PHOTO 4
1—Kit Bag Containing
1-3/8” x 1. 1/4” Bolt
1-3/8” Flat Washer
1-3/8” Flange Lock Nut
1-1/2” x 2 1/2” Bolt
1-1/2” Flat Washer
1-1/2” Lock Nut
INSTALLATION INSTRUCTIONS FORM NO. 82278
CAUTION: Any and all warranties including but not limited to any express warranties, implied warranty of merchant-
ability, or implied warranty of fitness for a particular purpose shall not apply to any product altered in any way outside
the premises of the manufacturer or to any product which is not installed in accordance with the written instructions
provided by the manufacturer for installation of the product.
