Rough Country 1189 - Manual (Page 2)

PHOTO 4
PHOTO 5
YJ INSTALLATION
1. Place vehicle on a flat surface and set emergency brake.
2. Remove the front valence, using a 3/8” wrench. Using a
T55 torx socket, remove the front bumper mounting hard-
ware and tow hooks if equipped.
3. If installing a winch at this time it is recommended that you
install the winch to the mounting plate, before installing the
plate on the vehicle.
4. Install the two large washers over the holes where the two
rear bolts where removed to level the plate. See PHOTO 1.
5. Place mounting plate on bumper and align holes. See
PHOTO 2.
6. Replace the 4 bumper bolts, using a T55 Torx bit, and
torque to 75 ft. lbs. If reinstalling aftermarket tow hooks use
a 3/4” socket, and install the provided bolts and washers,
and torque to 75 ft. lbs. See PHOTO 3
9. On the TJ the front valence can be replaced with some trimming, if you elect to keep the valance see
PHOTO 4 and 5 for required cutting.
10. Trim the valence as shown below and replace, using a 3/8” wrench.
11. Check the torque on all fasteners after the first use of the winch. Periodically inspect the components for
tightness.
YJ washer placement
YJ winch plate placement location.
YJ bolt placement.
PHOTO 1
PHOTO 2
PHOTO 3
