Rough Country 1087 - Manual

97– 06 TJ REAR TRACK BAR BRACKET FOR 2 1/2 LIFT
INSTALLATION INSTRUCTIONS
1. Disconnect the track bar from the axle bracket on driver side of vehicle using a T55 Torx bit.
2. Install the new track bar relocation bracket in the stock location with the supplied crush sleeve. See Photo 1.
Secure using the factory hardware in the factory location. Using a drill enlarge the two factory holes in the
factory mount using a 11/32” drill bit as shown in Photo 2 and install the 5/16” X 1” bolts, washers, nuts and
tighten using 1/2” wrench to 15 ft/lbs Do not install the track rod in the new bracket at this time.
3. Jack up the axle to compress the coil spring and to a align the track rod with the new mounting point. Install
using the supplied 12mm x 65mm bolt and flange lock nut. Tighten the bolt to 55 ft/lbs with a 18mm wrench.
92108700
Thank you for choosing Rough Country for your Jeep off road needs.
Please read all the instructions before beginning the installation.
PRODUCT USE INFORMATION
We will be happy to answer any questions regarding our products by calling us @ 800-222-7023 .Rough Country
will not be responsible for any product that is altered.
POST INSTALLATION
1. Check all fasteners for proper torque. Check to ensure there is adequate clearance between all rotating,
mobile, fixed and heated members. Check steering for interference and proper working order.
2. Re torque all fasteners after 500 miles. Visually inspect components and re torque fasteners during routine
vehicle service.
PHOTO 2
KIT CONTENTS
1-TRACK ROD BRACKET
1-POLY BAG CONTAINING
2-5/16” X 1” BOLTS
2-5/16” NUTS
4-5/16” WASHERS
1-12MM X 65MM BOLT
1-12MM FLANGE LOCK NUT
1-CRUSH SLEEVE
TOOLS NEEDED
DRILL
11/32” DRILL BIT
18MM WRENCH
1/2” WRENCH
T55 TORX HEAD BIT
12mm x 65mm bolt
installs here
Stock bolt installs
here
5/16” x 1” bolts
install here
PHOTO 1
