Rough Country 489P - Manual (Page 2)

6. Gently pull the bumper outward as shown in Figure 2. Carefully remove the lighting harness plugs, and any other
wiring attached to the bumper assembly to allow for removal noting the routing of the wiring. Place the bumper as-
sembly out of harms way to ensure that no damage occurs to the bumper.
7. The radiator cooler lower mounts will have to be removed to allow the cooler to move outward to gain access to the
front spring bolts. Remove bolts on both sides of cooler as shown in Figure 3 (Passenger Side Shown). Retain the
factory hardware for reuse.
8. Remove the factory track rod from the axle and the frame using a 30mm socket / wrench. Remove the factory track
bar. See Figure 4 & 5.
9. Make sure the axle is still being supported with the floor jack. On the front spring bolt, gently pull the radiator cooler
outward to remove the spring bolts. Remove spring bolts and retain for reuse. See Figure #6. Remove factory rear
spring shackle bolts. See Figure #7. Retain for reuse.
10. Remove the factory front spring bolts. See Figure #6 and factory rear spring shackle bolts. See Figure #7.
9.
Figure 2 Figure 3
Figure 4 Figure 5
Figure 6 Figure 7
