• Check clearance on engine and engine components. Check clearance between the fan and the fan shroud.
• Re torque all fasteners after 500 miles. Visually inspect components and re torque fasten-
ers during routine vehicle service.
POST INSTALLATION
5. Remove the cross bolt and remove the isolator from the vehicle. See Photo 3. NOTE: On vehicles equipped with a
4cyl motor, it will be necessary to remove the alternator to remove the stock cross bolt from the isolator. Also on
vehicles equipped with air conditioning, the condenser pump will not allow enough clearance to remove the stock
cross bolt, therefore the engine support bracket must be removed.
6. Using a cutting tool, remove 1/4” from the motor mount stud. Take care not to damage the threads. See Photo 4.
7. Install the supplied stud extension onto the stud and tighten using a 16mm wrench. Make sure the stud extension is
fully seated against the bottom of the motor mount. See Photo 5.
8. Slip the motor mount spacer over the stud and reinstall on the vehicle and secure to the frame with the stock nut and
the supplied 10mm x 60mm bolt /washer. See Photo 6. Do not fully tighten at this time. If the engine bracket was
removed, install it at this time.
9. Adjust the height of the jack and reinstall the stock cross bolt in the mount. Do not tighten.
10. Repeat steps for Driver side. When driver side is completed, tighten all hardware.
Photo 3 Photo 4
Photo 5 Photo 6
KIT COMPONENTS
