25. Install the new pitman arm into the stock location on the sector shaft, using stock hardware and torque nut to 185 ft.
lbs. See PHOTO 9.
26. Reinstall the drag link onto the pitman arm using stock hardware.
27. Install the supplied sway bar link bracket as shown in PHOTO 10 with the supplied 10mm x 55mm hardware.
28. Install the supplied bushings / sleeves in the new sway bar links and install in the new sway bar bracket as shown
PHOTO 11 and on the factory axle location with supplied 12mm x 65mm hardware. See PHOTO 12. Tighten hard-
ware.
29. Raise the front axle with a floor jack to slightly compress the coil springs.
30. Install the lower end of the shocks in the stock location and tighten using stock hardware.
31. Lower vehicle to the ground. Install the tires / wheels.
32. Torque the fasteners to the following specifications:
Lower suspension arm cam nut………………… 110 ft/lbs
Lower suspension arm rear nut…………………. 88 ft/lbs
Upper suspension arm axle nut…………………. 89 ft/lbs
Upper suspension arm frame nut……………….. 62 ft/lbs
PHOTO10 PHOTO11
PHOTO11 PHOTO12
