c. Sensitivity
MOTION GAIN
DISCRIM MOTION GAIN
SENSITIVITY PIN -PT GAIN
AUDIO TUNE
PROGRAMS
SET UP BACK
This sets the sensitivity of the audio signal and the ID display in normal search or motion mode. The level is set by
rotating the MENU/SCROLL control, the current level is indicated on the display. Once the desired level has been set
by rotating the MENU/SCROLL control, press ENTER to store the setting.
NOTE: This setting has no effect on the RADAR display or audio level in Pin Point mode.
TIP! This level should be set as high as possible without the CSR1 spuriously sounding off.
PIN - PT GAIN
DISCRIM MOTION GAIN
SENSITIVITY PIN -PT GAIN
AUDIO TUNE
PROGRAMS
SET UP BACK
This sets the sensitivity of the Pin Point, or non-motion, mode. When Pin-Pt Gain is selected the CSR1 automatically
selects Pin Point mode. Once the desired level has been set by rotating the MENU/SCROLL control press then
ENTER button to store the setting. This setting also alters the sensitivity of the RADAR display.
NOTE: This setting has no effect on the normal or motion search mode.
TUNE
DISCRIM MOTION GAIN
SENSITIVITY PIN -PT GAIN
AUDIO TUNE
PROGRAMS
SET UP BACK
This sets the threshold or background tone. This is only audible with Silent Search turned off. As soon as Tune is
selected then Silent Search will be turned OFF so that the background tone will be heard. Once the desired level has
been set by rotating the MENU/SCROLL control press the ENTER button to store the setting.
d. Audio
DISCRIMINATION
DISCRIM DISCRIM PIN -PT OFF
SENSITIVITY SIL SEARCH PIN -PT ON
AUDIO MODE MOTION OFF
PROGRAMS MOTION ON
SET UP BACK
This enables or disables Audio Discrimination for both motion and Pin Point modes. Audio Discrimination gives the
operator an indication of the composition of the target by varying the pitch/tone of the audio signal. The higher the
pitch the further up the ID scale the target will be. For all modes, highlight the desired option by rotating the MENU/
SCROLL control and then press the ENTER button.
NOTE: Pin Point and motion Audio Discrimination can be set independently.
PIN - PT OFF: turns Audio Discrimination OFF for Pin Point Mode.
PIN - PT ON: turns Audio Discrim ON for Pin Point Mode: it gives a continuous pitch change for the entire ID range.
MOTION OFF: This turns Audio Discrimination OFF for motion Mode.
MOTION ON: This turns Audio Discrimination ON for motion Mode. In this mode bad signals such as Iron will give a
low tone. Good signals will give a high tone.
NOTE: No tone will be heard if the object has been rejected by the ID.
TIP! Best results will be obtained in this mode if Silent Search is on.
