added NAS function to back up all kind of IP cameras on the internet
works with free Central Management System (CMS) software for
offsite backup
 local and remote control completely independent
 HDMI video output resolution up to 1080P
 optional monitor: MONSCA8
adapter: PAC916T
HDMI cable: Professional or Premium
 optional hard disk: HD500GB/S, HD1TB/S, HD2TB/S
 USB mouse: included
 IR remote control: included
 IP cameras: suitable: CAMIP11, CAMIP12
also compatible with: CAMIP9, CAMIP13, CAMIP14 & ONVIF cameras
 compatible with powerline adapter: EM8017, EM8024, EM8025, EM8026
 optional router: EM4542, EM4553, EM4570, PCRT1
5. Overview
Refer to the illustrations on page 2 of this manual.
Front panel
1
POWER
LED indicator: the NVR is switched on
2
ALARM
LED indicator: an alarm event occurs
3
WAN
LED indicator: the NVR is connected to internet
4
LAN
LED indicator: the NVR is connected to the LAN
5 SATA LED indicator: SATA hard disk is active
6 HDD1/HDD2 LED indicator: up to two hard disks are installed in the NVR and connected well
7 USB port
Insert a compatible USB flash drive for video backup.
Note: For the list of compatible USB flash drives, refer to the full manual on the
CD-ROM.
8
mouse port
Insert a mouse (included).
Back panel
9 RS485 RS 485 port
10 SATA Connect an external SATA hard disk
11
HDMI video output
port
Connect to a monitor that supports high-definition video output (HDMI port).
Note: Use an appropriate adapter (not incl.) to connect a monitor with VGA or
composite connectors.
12 LAN Connect to local IP cameras via an 8P8C (RJ45) network cable.
13 WAN Connect to internet via an 8P8C (RJ45) network cable
14 AUDIO OUT Connect to an amplifier audio line-in.
15 DC 19V IN Connect to the power supply adapter (incl.).
6. Installing the hard disk drive
1. Obtain a suitable hard disk (not included), type ESATA (Serial Advanced Technology Attachment). The hard
disk must be formatted.
2. Make sure to unplug the device from the mains before servicing and do not touch any electronic circuitry
to avoid electrostatic discharge.
3. Loosen the screws and remove the top cover.
4. Find the hard disk bracket in the NVR, and insert the hard disk in the bracket.
5. With the PCB side facing up, connect the hard disk to the power connector and the data connector.
6. Fasten the hard disk with the supplied screws, two for each side.
