COMPASS Control Panel
Complete, Operational, Maintenance, Performance and Security System
The brand new COMPASS control panel on the Cat ® E Series mini
hydraulic excavators was specifically designed by Caterpillar for
compact excavators. It adds several new features to the machines
increasing the amount of customer value. All of the following features
are now standard on all five of the new E Series models.
C omplete – All of the control panel features are standard on all five
of the new E Series models
O peration – Simple operation of the pattern changer, hydraulic quick
coupler and fuel gauge visibility all at the push of a button
M aintenance – Maintenance intervals, diagnostics and work hours
P erformance – Save up to 20% fuel while maintaining optimum
performance levels
A nd
S ecurity – Anti theft device with individual user and master
passwords
S ystem – Ergonomically designed control panel
Passcode Protected Security System
A standard anti-theft device now comes on every E Series compact
excavator. A five digit alphanumeric password is required to start the
machine when the anti-theft feature is enabled. There is a master
password and up to five user passwords can be created by the
owner if desired.
Keep your machine safe on a busy job site by locking it when you
are not around
Adjustable Auxiliary Work Tool Flow Control
The E Series machines now have simple adjustability of the flow
going down the boom and stick to the work tool. Both the standard
main line and optional secondary auxiliary hydraulics can be adjusted
on a scale of 1–15 through a few buttons on the control panel.
Adjust the flow to your different tools with a simple push of a button
