303.5E CR, 304E CR, 305E CR, 305.5E CR Specifications
Engine Travel System
Engine Model Travel Speed – High 4.6 km/h 2.8 mph
303.5E CR Cat ® C1.8 Travel Speed – Low
304E CR/305E CR/305.5E CR Cat ® C2.4 303.5E CR/304E CR/305E CR 2.6 km/h 1.6 mph
Rated Net Power (ISO 9249) 305.5E CR 2.8 km/h 1.7 mph
303.5E CR 23.6 kW 31.6 hp Maximum Traction Force – High Speed
304E CR/305E CR 30 kW 40.2 hp 303.5E CR 16.9 kN 3,799 lb
305.5E CR 32.9 kW 44.2 hp 304E CR 16.8 kN 3,777 lb
Gross Power 305E CR 24.1 kN 5,418 lb
303.5E CR 24.8 kW 33.3 hp 305.5E CR 26.8 kN 6,025 lb
304E CR/305E CR 31.2 kW 41.8 hp Maximum Traction Force – Low Speed
305.5E CR 34.1 kW 45.7 hp 303.5E CR 31 kN 6,969 lb
Bore 87 mm 3.4 in 304E CR 30.8 kN 6,921 lb
Stroke 102.4 mm 4 in 305E CR 45.2 kN 10,161 lb
Displacement 305.5E CR 47.8 kN 10,745 lb
303.5E CR/304E CR 1.8 L 110 in 3 Ground Pressure
305E CR/305.5E CR 2.4 L 146 in 3 303.5E CR 32.1 kPa 4.7 psi
Weights*
304E CR
305E CR
29.1 kPa
28.2 kPa
4.2 psi
4.1 psi
Operating Weight with Canopy 305.5E CR 30 kPa 4.4 psi
303.5E CR
304E CR
3508 kg
3854 kg
7,734 lb
8,497 lb
Service Refill Capacities
305E CR 4915 kg 10,836 lb Cooling System
305.5E CR 5270 kg 11,618 lb 303.5E CR/304E CR 5.5 L 1.5 gal
Operating Weight with Cab 305E CR/305.5E CR 10.5 L 2.8 gal
303.5E CR 3692 kg 8,139 lb Engine Oil
304E CR 4009 kg 8,838 lb 303.5E CR/304E CR 7.0 L 1.8 gal
305E CR 5088 kg 11,217 lb 305E CR/305.5E CR 9.5 L 2.5 gal
305.5E CR 5415 kg 11,938 lb Fuel Tank
* Weight includes rubber tracks, bucket, operator, full fuel 303.5E CR/304E CR 46 L 12.2 gal
and auxiliary lines. 305E CR/305.5E CR 63 L 16.6 gal
Hydraulic Tank
303.5E CR/304E CR 42.3 L 11.2 gal
305E CR/305.5E CR 68.3 L 18 gal
Hydraulic System
303.5E CR/304E CR 65 L 17.2 gal
305E CR/305.5E CR 78 L 20.6 gal
14
