B-Series 3 Compact Track and Multi Terrain Loaders Standard Equipment
Standard equipment may vary. Consult your Cat dealer for details.
ELECTRICAL
12 volt Electrical System
85 ampere Alternator (247B Series 3)
90 ampere Alternator (257B/259B Series 3)
Automatic Glow Plug Activation
Heavy Duty Battery, 880 CCA
(standard on the 257B/259B Series 3)
Ignition Key Start/Stop Switch
Lights: Gauge backlighting, two rear
tail lights, two adjustable front and
rear halogen lights, dome light.
OPERATOR ENVIRONMENT
Gauges: Fuel level, hour meter
Operator Warning System Indicators:
Air filter restriction, alternator output,
armrest raised/operator out of seat,
engine coolant temperature, engine oil
pressure, glow plug activation, hydraulic
filter restriction, hydraulic oil temperature,
parking brake engaged
Vinyl seat
Pull Down Ergonomic Contoured Armrest
Control Interlock System, when operator
leaves seat or armrest raised: Hydraulic
system disables, hydrostatic transmission
disables, parking brake engages
ROPS Cab, Open, Tilt Up
FOPS, Level I
Top and Rear Windows
Floor Mat
Interior Rear View Mirror
12 volt Electric Socket
Horn
Backup Alarm
Hand and Foot Throttle
POWER TRAIN
Cat C2.2 T Diesel Engine (247B Series 3)
Cat C3.4 DIT Diesel Engine
(257B/259B Series 3)
Engines are Tier 4 Interim/Stage IIIA
Compliant
Air Cleaner, Dual Element, Radial Seal
S·O·S
SM Sampling Valve, Hydraulic Oil
Filters, Spin-on, Hydraulic
Filters, Bayonet-type, Fuel and
Water Separator
Tilt Up Radiator/Hydraulic Oil Cooler
Spring Applied, Hydraulically Released
Parking Brakes
Hydrostatic Transmission
OTHER
Engine Enclosure, Lockable
Extended Life Antifreeze, –36° C (–33° F)
Machine Tie Down Points (4)
Support, Lift Arm
Hydraulic Oil Level Sight Gauge
Radiator Coolant Level Sight Gauge
Radiator, Expansion Bottle
Cat ToughGuard™ Hose
Auxiliary, Hydraulics, Continuous Flow
Heavy Duty, Flat Faced Quick Disconnects
Split D-Ring to Route Work Tool Hoses
Along Side of Left Lift Arm
Electrical Outlet, Beacon
Belly Pan Cleanout
MANDATORY EQUIPMENT
Quick Coupler, Mechanical or Hydraulic
Seat Belt, 50 mm (2 in) or 75 mm (3 in)
EU Preparation Package
(Europe only – includes Demand Fan)
Cooling Fan, Demand or Standard
(EU Preparation Package includes
Demand Fan)
Comfort Packages
(must select one of the following):
• Open ROPS (C0): Static Seat
• Open ROPS (C1): Suspension Seat,
Deluxe Headliner
• Enclosed ROPS (C2): Features of
C1 Package plus Heater, Cab Door,
Side Windows, Cup Holder,
Cab Debris Barrier
• Enclosed ROPS (C3): Features of
C2 Package plus Air Conditioner
Control Packages for the 247B Series 3
(must select one of the following):
• Control Package 1: On/Off Auxiliary
Hydraulics Basic
• Control Package 2: Proportional
Auxiliary Hydraulics Deluxe
• Control Package 3: Proportional
Auxiliary Hydraulics Deluxe,
Work Tool Harness
Control Packages for the 257B Series 3
(must select one of the following):
• Control Package 1: On/Off Auxiliary
Hydraulics Basic
• Control Package 2: Proportional
Auxiliary Hydraulics Deluxe, 1 Speed
• Control Package 3: Proportional
Auxiliary Hydraulics Deluxe, 1 Speed,
Work Tool Harness
• Control Package 4: Proportional
Auxiliary Hydraulics Deluxe, 2 Speed
• Control Package 5: Proportional
Auxiliary Hydraulics Deluxe, 2 Speed,
Work Tool Harness
• Control Package 6: High Flow
Hydraulics, 1 Speed
• Control Package 7: High Flow
Hydraulics, 2 Speed
Control Packages for the 259B Series 3
(must select one of the following):
• Control Package 1: Proportional
Auxiliary Hydraulics Deluxe, 2 Speed
• Control Package 2: Proportional
Auxiliary Hydraulics Deluxe, 2 Speed,
Work Tool Harness
• Control Package 3: High Flow
Hydraulics, 2 Speed
