15 450E Backhoe Loader specifications
Operating Specifications – Backhoe
Turning Circle: outside, front wheels 8.36 m 27 ft 5 in
Turning Circle: outside, 11.18 m 36 ft 8 in
widest loading bucket
• ISO 5010.
• 4WD (off inner wheel not braked).
Service Refills
Cooling System, A/C 24.3 L 6.4 gal
Cooling System, High-Ambient 25.6 L 6.8 gal
Fuel Tank 145 L 38.4 gal
Engine Oil w/Filter 8.5 L 2.2 gal
Transmission, AWD, Auto Shift 21 L 5.6 gal
Rear Axle 19 L 5 gal
Front Axle, 4WD 11 L 2.9 gal
Front Axle, Planetaries 0.8 L 0.2 gal
Hydraulic System 100 L 26.5 gal
Hydraulic Tank 50 L 13.2 gal
Axle Ratings
Front Axle, 4WD, Static 22 944 kg 50,582 lb
Dynamic 9178 kg 20,233 lb
Rear Axle, Static 23 250 kg 51,257 lb
Dynamic 9300 kg 20,503 lb
• 4WD axle is pendulum mounted and permanently sealed and
lubricated, requiring no daily maintenance. Also features
double-acting steering cylinder with 52° steering angle for
increased maneuverability. Oscillation 10° each direction
from centerline.
Brakes
Features:
• Brakes meet the following standards: SAE J1473 and
ISO 3450 requirements.
• Boosted, self-adjusting, completely enclosed and sealed
outboard brakes allow easier servicing.
• Foot operated brake pedals can be interlocked for roading.
• Parking/secondary brakes are independent of the service
brake system. Parking brake is mechanically applied through
an adjustable hand lever located on the right console.
Hydraulic System
Circuit Type Closed center,
load sensing
Pump Capacity (@ 2,200 rpm) 194 L/min 51.3 gal/min
System Pressure – Backhoe 26 200 kPa 3,800 psi
System Pressure – Loader 24 483 kPa 3,550 psi
Pump Type Variable-flow, axial piston,
secondary gear
Steering Type Ackerman
Power Steering Hydrostatic, Hand
Metering Unit
Steering Cylinder One double-acting
Axle Oscillation 10º
4WD Cylinder – Bore 85 mm 3.35 in
Stroke 236 mm 9.29 in
Rod Diameter 42 mm 1.65 in
Brake System Boosted, outboard,
oil-immersed, multiple disc
Power Train
Auto-Shift (opt), Forward 1st 6 km/h 3.7 mph
Forward 2nd 9.6 km/h 6 mph
Forward 3rd 20 km/h 12 mph
Forward 4th 27 km/h 17 mph
Forward 5th 40 km/h 25 mph
Auto-Shift (opt), Reverse 1st 6 km/h 3.7 mph
Reverse 2nd 13 km/h 7.8 mph
Reverse 3rd 27 km/h 17 mph
• Auto-Shift automatically shifts between second gear and
highest selected gear.
• Forward/reverse electric power shuttle is controlled by
a conveniently placed, hand operated lever that provides
instant direction changes between forward and reverse
through power hydraulic clutches.
• Torque converter free-wheel clutch allows the converter
stator to free wheel during high speed, low torque
conditions such as roading.
• Single-stage, 2.38:1 stall ratio at 880 N·m (649 lb ft)
stall torque.
• Travel speeds at full governor on level ground.
