14 450E Backhoe Loader specifications
Backhoe
Dig Depth – Standard 5260 mm 17 ft 3 in
E-Stick Retracted 5260 mm 17 ft 3 in
E-Stick Extended 6501 mm 21 ft 4 in
Reach from Swing Pivot – Standard 6704 mm 22 ft
E-Stick Retracted 6704 mm 22 ft
E-Stick Extended 7886 mm 25 ft 10 in
Bucket Rotation 198º
Bucket Dig Force – Standard 78.9 kN 17,746 lb
E-Stick Retracted 78.9 kN 17,746 lb
E-Stick Extended 78.9 kN 17,746 lb
Stick Dig Force – Standard 52.4 kN 11,780 lb
E-Stick Retracted 53.1 kN 11,939 lb
E-Stick Extended 40 kN 9,009 lb
Stick Lift @ 2440 mm (8 ft) – Standard 3811 kg 8,401 lb
E-Stick Retracted 3667 kg 8,084 lb
E-Stick Extended 2048 kg 4,514 lb
Loading Height – Standard 4440 mm 14 ft 7 in
E-Stick Retracted 4439 mm 14 ft 7 in
E-Stick Extended 5194 mm 17 ft
Loading Reach – Standard 2100 mm 6 ft 11 in
E-Stick Retracted 2100 mm 6 ft 11 in
E-Stick Extended 3112 mm 10 ft 3 in
Loader
Bucket Capacity – General Purpose 1.34 m 3 1.75 yd 3
Bucket Width – General Purpose 2434 mm 8 ft
Dump Height @ Max Angle – 2666 mm 8 ft 9 in
Single Tilt
Dump Reach @ Max Angle – 850 mm 2 ft 9 in
Single Tilt
Dig Depth – Single Tilt 146 mm 6 in
Lift Capacity @ Full Height – 3570 kg 7,871 lb
Single Tilt
Bucket Breakout Force – Single Tilt 50.6 kN 11,375 lb
Engine
Engine Model (Standard) Cat ® C4.4
Gross Power – SAE J1995 102 kW 137 hp
Gross Power – ISO 14396 102 kW 137 hp
Net Power – SAE J1349 92 kW 124 hp
Net Power – ISO 9249 93 kW 125 hp
Net Power – EEC 80/1269 93 kW 125 hp
Bore 105 mm 4.13 in
Stroke 127 mm 5 in
Displacement 4.4 L 268 in 3
Net Torque Rise @ 1,400 rpm – 28%
Standard
Net Peak Torque @ 1,400 rpm – 514 N·m 380 lb ft
Standard – SAE J1349
• The net power ratings apply at 2,200 rpm when tested under
the specified conditions for the specified standard.
• Net power advertised is the power available at the flywheel
when the engine is equipped with fan, air cleaner, muffler
and alternator.
• Based on standard air conditions of 25° C (77° F) and 99 kPa
(29.32 in) in dry barometer.
• Used 35° API gravity fuel having an LHV of 42 780 kJ/kg
(18,390 BTU/lb) when used at 30° C (89° F) (reference a fuel
density of 838.9 g/L [7.001 lb/gal]).
• No derating required up to 3000 m (9,842 ft).
• Net torque rise meets SAE J1349.
Weights
Operating Weight – Nominal 10 950 kg 24,141 lb
Operating Weight – Maximum 12 300 kg 27,115 lb
Cab, ROPS/FOPS 252 kg 556 lb
Air Conditioning 71 kg 157 lb
MP Bucket 1.1 m 3 (1.5 yd 3 ) –86 kg –190 lb
w/Fold-Over Fork
MP Bucket 1.1 m 3 (1.5 yd 3 ) w/o 105 kg 231 lb
Fold-Over Fork
Extendible Stick (no weights) 285 kg 628 lb
• Total gross machine weight not to exceed 12 300 kg (27,115 lb).
