STARTING CAPABILITIES (sKVA)
FUEL
Natural Gas
Single-Phase 120/240VAC @1.0pf 200 Amps: 833
Three-Phase 120/208VAC @0.8pf 200 Amps: 695
Three-Phase 120/240VAC @0.8pf 200 Amps: 602
Three-Phase 277/480VAC @0.8pf 200 Amps: 301
Three-Phase 346/600VAC @0.8pf 200 Amps: 241
sKVA vs. Voltage Dip
480VAC 208/240VAC
Alternator kW 10% 15% 20% 25% 30% 35% 10% 15% 20% 25% 30% 35%
Standard 200 187 280 373 467 560 653 140 210 280 350 420 490
Upsize 1 250 263 395 527 658 790 922 197 296 395 494 593 692
Upsize 2 300 303 454 605 757 908 1059 227 341 454 568 681 794
COOLING
COMBUSTION AIR REQUIREMENTS
ENGINE EXHAUST
Flow at Rated Power cfm 432
Rated Engine Speed rpm 1800
Horsepower at Rated kW** hp 304
Piston Speed ft/min 1773
BMEP psi 179
** Refer to “Emissions Data Sheet” for maximum bHP for EPA and SCAQMD permitting purposes.
Exhaust Flow (Rated Output) cfm (m 3 /min) 1499 (42.4)
Maximum Recommended Back Pressure inHg 1.5
Exhaust Temp (Rated Output) ºF (ºC) 1384 (751)
Exhaust Outlet Size (Catalyst) in 5.0"
POWER RATINGS (kW)
Fuel Consumption Rates*
Natural Gas
Percent Load ft 3 /hr m 3 /hr
25% 1050 29.7
50% 1523 43.1
75% 2026 57.4
100% 2578 73.0
* Refer to "Emissions Data Sheet" for maximum fuel
flow for EPA and SCAQMD permitting purposes.
Air Flow (inlet air combustion and radiator) ft 3 /min (m 3 /min) 9432 (267)
System Coolant Capacity Gal (Liters) 6.1 (23.1)
Heat Rejection to Coolant BTU/hr 670,280
Max. Operating Air Temp on Radiator ºF (ºC) 122 (50)
Max. Ambient Temperature ºF (ºC) 104 (40)
Maximum Radiator Backpressure in H
2
O 1.50
3 of 5
G200LG operating data (60Hz)
G200LG 200kW
Deration – Operational characteristics consider maximum ambient conditions. Derate factors may apply under atypical site conditions. All performance ratings in accordance with ISO3046,
BS5514, ISO8528 and DIN6271 standards.
