914G2/IT14G2 Compact Wheel Loader/Integrated Toolcarrier Specifications
914G2 Operating Specifications
General
Purpose Buckets Penetration
Buckets
With Bolt-On
Cutting Edge
With Bolt-On
Teeth and
Segments
With Bolt-On
Teeth
With Flush
Mounted Teeth
Rated bucket capacity (§) m 3 1.3 1.4 1.3 1.4 1.2 1.3 1.3 1.4
yd 3 1.7 1.8 1.7 1.8 1.6 1.7 1.7 1.8
Struck capacity (§) m 3 1.1 1.2 1.1 1.2 1.0 1.1 1.1 1.2
yd 3 1.4 1.5 1.4 1.5 1.3 1.5 1.5 1.5
Width mm 2401 2401 2424 2424 2424 2424 2434 2434
ft/in 7'10.5" 7'10.5" 7'11.4" 7'11.4" 7'11.4" 7'11.4" 7'11.8" 7'11.8"
Dump clearance at full lift and 45° discharge (§) mm 2659 2623 2667 2632 2715 2680 2680 2680
ft/in 8'9" 8'7" 8'9" 8'7" 8'11" 8'10" 8'10" 8'10"
Reach at full lift and 45° discharge (§) mm 973 1008 964 1000 944 979 979 979
ft/in 3'2" 3'4" 3'2" 3'3" 3'1" 3'3" 3'3" 3'3"
Reach at 45° discharge and 2130 mm (7 ft)
clearance (§) mm 1331 1348 1282 1297 1259 1275 1287 1249
ft/in 4'4" 4'5" 4'2" 4'3" 4'2" 4'2" 4'3" 4'1"
Reach with lift arms horizontal and bucket level mm 1980 2030 1970 2020 1920 1970 1970 1970
ft/in 6'6" 6'8" 6'6" 6'8" 6'4" 6'6" 6'6" 6'6"
Digging depth (§) mm 89 89 89 89 70 70 70 70
in 3.5" 3.5" 3.5" 3.5" 2.8" 2.8" 2.8" 2.8"
Overall length mm 6229 6279 6328 6378 6310 6360 6358 6438
ft/in 20'5" 20'7" 20'9" 20'11" 20'8" 20'10" 20'10" 21'1"
Overall height with bucket at full raise (§) mm 4390 4442 4390 4442 4390 4442 4442 4442
ft/in 14'5" 14'7" 14'5" 14'7" 14'5" 14'7" 14'7" 14'7"
Loader clearance circle with bucket
in carry position m 10.34 10.37 10.42 10.45 10.42 10.45 10.44 10.49
ft/in 33'11" 34'0" 34'2" 34'4" 34'2" 34'4" 34'3" 34'5"
Static tipping load straight* (§) kg 6098 6069 6059 6029 6169 6166 6183 6011
lb 13,446 13,382 13,360 13,294 13,603 13,602 13,634 13,254
Static tipping load full 40° turn* (§) kg 5323 5295 5284 5256 5415 5387 5404 5232
lb 11,737 11,675 11,651 11,589 11,940 11,878 11,916 11,537
Breakout force (§) kg 6367 5971 6415 6010 6929 6469 6484 6374
lb 14,007 13,136 14,113 13,222 15,246 14,232 14,265 14,055
7378 7391 7409 7422 7336 7349 7336 7500
16,262 16,297 16,337 16,366 16,176 16,205 16,176 16,538
Operating weight* kg
lb
*Static tipping and operating weights shown are for high-speed version 914G2 and include lubricants, full fuel tank, ROPS cab, 80 kg
(176 lb) operator and 17.5-R25 (L2 equivalent) tires.
NOTE: Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers (SAE).
SAE Standards J732 and J742 govern loader rating, denoted in the text by (§).
8
