26 994F Wheel Loader specifications
Operating Specifications – Super High Lift
Machines only equipped with 58/85-57 tires & Coal Bucket
Coal Bucket
(6500 mm/256 in)
Serrated Edge
Coal Bucket
Rated capacity (§) m 3 36
yd 3 47
Struck capacity (§) m 3 30
yd 3 39.2
Dump clearance at full lift mm 7336
and 45 ° discharge (§) ft/in 24' 0"
Reach at full lift mm 3386
and 45
° discharge (§)
ft/in 11' 1"
Reach with lift arms mm 7543
horizontal and bucket level ft/in 24' 9"
Digging depth (§) mm 299
ft/in 1' 0"
Overall length (§) mm 19 504
ft/in 63' 1"
Overall height with bucket mm 14 412
at full raise (§) ft/in 47' 3"
Loader clearance circle with mm 14 262
bucket in carry position (§) ft/in 46' 10"
Static tipping load straight** (§) kg 83 444
lb 183,962
Static tipping load kg 69 748
at full 40
° turn** (§)
lb 153,768
Breakout force*** (§) kN 693
lb 155,925
Operating weight** (§) kg 211 970
lb 467,313
Width over tires mm 5524
58/85-57 in 217
(§) Specifications rating conform to all applicable standards recommended by the Society of Automotive Engineers. SAE standard J732c governs loader ratings
and is denoted in the chart by (§).
* Dimensions are measured to the tip of the bucket teeth to provide accurate clearance data. SAE standard specifies the cutting edge.
** Static tipping load and operating weight shown are based on standard machine configuration with 53.5/85-57 tires, full fuel tank, coolant and lubricants.
*** Measured 102 mm (4 in) behind tip of cutting edge with the bucket hinge pin as pivot point in accordance with SAE J732c.
