Operating Specifications
Bucket Type
Edge Type
Capacity – Rated (§)
m
3
yd
3
Capacity – Struck (§)
m
3
yd
3
Width (§)
mm
ft/in
Dump Clearance at Maximum Lift and 45° Discharge (§)
mm
ft/in
Reach at Maximum Lift and 45° Discharge (§)
mm
ft/in
Reach at Level Lift Arm and Bucket Level (§)
mm
ft/in
Digging Depth (§)
mm
in
Overall Length
mm
ft/in
Overall Height with Bucket at Maximum Lift
mm
ft/in
Loader Clearance Circle with Bucket at Carry Position (§)
mm
ft/in
Static Tipping Load, Straight (ISO)*
kg
lb
Static Tipping Load, Straight (Rigid Tire)*
kg
lb
Static Tipping Load, Articulated (ISO)*
kg
lb
Static Tipping Load, Articulated (Rigid Tire)*
kg
lb
Breakout Force** (§)
kN
lb
Operating Weight*
kg
lb
General Purpose – Fusion QC
Bolt-On
Teeth and
Bolt-On
Teeth and
Edges
Segments
Teeth
Edges
Segments
Teeth
3.10
3.10
2.90
3.30
3.30
3.10
4.05
4.05
3.79
4.32
4.32
4.05
2.76
2.76
2.54
2.94
2.94
2.72
3.61
3.61
3.32
3.85
3.85
3.56
2927
2994
2994
2927
2994
2994
9'7"
9'9"
9'9"
9'7"
9'9"
9'9"
2837
2718
2718
2798
2679
2679
9'3"
8'11"
8'11"
9'2"
8'9"
8'9"
1475
1585
1585
1503
1613
1613
4'10"
5'2"
5'2"
4'11"
5'3"
5'3"
2748
2909
2909
2797
2958
2958
9'0"
9'6"
9'6"
9'2"
9'8"
9'8"
90
90
60
90
90
60
3.5"
3.5"
2.3"
3.5"
3.5"
2.3"
8222
8395
8395
8271
8444
8444
27'0"
27'7"
27'7"
27'2"
27'9"
27'9"
5558
5558
5558
5604
5604
5604
18'3"
18'3"
18'3"
18'5"
18'5"
18'5"
13 789
13 961
13 961
13 818
13 991
13 991
45'3"
45'10"
45'10"
45'5"
45'11"
45'11"
12 155
12 015
12 344
12 065
11 924
12 252
26,790
26,481
27,208
26,591
26,280
27,004
12 896
12 754
13 096
12 808
12 665
13 006
28,423
28,111
28,865
28,230
27,915
28,666
10 448
10 308
10 620
10 363
10 221
10 532
23,029
22,720
23,407
22,840
22,529
23,214
11 204
11 062
11 386
11 120
10 978
11 301
24,694
24,382
25,096
24,510
24,196
24,908
153
152
166
147
146
159
34,451
34,172
37,295
33,132
32,855
35,769
19 894
20 002
19 845
19 941
20 049
19 892
43,847
44,085
43,739
43,949
44,187
43,841
* Static tipping loads and operating weights shown are based on a global machine configuration with Michelin 23.5R25 XHA2 L3 Radial
tires, full fluids, operator, standard counterweight, standard linkage, cold start, roading fenders, Product Link, open differential axles
(front/rear), power train guard, secondary steering, and sound suppression.
** Measured 102 mm (4") behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732C.
*** Rock bucket specifications are given on Michelin 23.5R25 XLDD2 L5 Radial tires.
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers, including
SAE Standard J732C governing loader ratings.
(ISO) Full compliance to ISO 14397-1 (2007) Sections 1 thru 6, which requires 2% verification between calculations and testing.
(Rigid Tire) Compliance to ISO 14397-1 (2007) Sections 1 thru 5.
25
