Operating Specifications
Bucket Type
Edge Type
Capacity – Rated (§)
m
3
yd
3
Capacity – Struck (§)
m
3
yd
3
Width (§)
mm
ft/in
Dump Clearance at Maximum Lift and 45° Discharge (§)
mm
ft/in
Reach at Maximum Lift and 45° Discharge (§)
mm
ft/in
Reach at Level Lift Arm and Bucket Level (§)
mm
ft/in
Digging Depth (§)
mm
in
Overall Length
mm
ft/in
Overall Height with Bucket at Maximum Lift
mm
ft/in
Loader Clearance Circle with Bucket at Carry Position (§)
mm
ft/in
Static Tipping Load, Straight (ISO)*
kg
lb
Static Tipping Load, Straight (Rigid Tire)*
kg
lb
Static Tipping Load, Articulated (ISO)*
kg
lb
Static Tipping Load, Articulated (Rigid Tire)*
kg
lb
Breakout Force** (§)
kN
lb
Operating Weight*
kg
lb
General Purpose – Pin On
Bolt-On
Teeth and
Bolt-On
Teeth and
Edges
Segments
Teeth
Edges
Segments
Teeth
2.70
2.70
2.50
2.90
2.90
2.70
3.53
3.53
3.27
3.79
3.79
3.53
2.30
2.30
2.11
2.55
2.55
2.33
3.01
3.01
2.76
3.34
3.34
3.05
2927
2994
2994
2927
2994
2994
9'7"
9'9"
9'9"
9'7"
9'9"
9'9"
2975
2859
2859
2919
2802
2802
9'9"
9'4"
9'4"
9'6"
9'2"
9'2"
1356
1469
1469
1395
1506
1506
4'5"
4'9"
4'9"
4'6"
4'11"
4'11"
2562
2723
2723
2631
2792
2792
8'4"
8'11"
8'11"
8'7"
9'1"
9'1"
90
90
60
90
90
60
3.5"
3.5"
2.3"
3.5"
3.5"
2.3"
8036
8209
8209
8105
8278
8278
26'5"
27'0"
27'0"
26'8"
27'2"
27'2"
5392
5392
5392
5464
5464
5464
17'9"
17'9"
17'9"
18'0"
18'0"
18'0"
13 689
13 856
13 856
13 729
13 897
13 897
44'11"
45'6"
45'6"
45'1"
45'8"
45'8"
12 974
12 836
13 135
12 833
12 694
12 985
28,596
28,291
28,949
28,285
27,977
28,619
13 719
13 580
13 887
13 582
13 441
13 740
30,238
29,930
30,608
29,935
29,624
30,284
11 230
11 092
11 372
11 094
10 955
11 228
24,752
24,447
25,064
24,453
24,145
24,747
11 990
11 850
12 138
11 857
11 716
11 997
26,427
26,119
26,754
26,134
25,823
26,442
180
178
197
169
167
184
40,442
40,157
44,336
37,997
37,715
41,441
19 303
19 411
19 254
19 388
19 496
19 339
42,544
42,782
42,436
42,730
42,968
42,622
* Static tipping loads and operating weights shown are based on a global machine configuration with Michelin 23.5R25 XHA2 L3 Radial
tires, full fluids, operator, standard counterweight, standard linkage, cold start, roading fenders, Product Link, open differential axles
(front/rear), power train guard, secondary steering, and sound suppression.
** Measured 102 mm (4") behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732C.
*** Rock bucket specifications are given on Michelin 23.5R25 XLDD2 L5 Radial tires.
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers, including
SAE Standard J732C governing loader ratings.
(ISO) Full compliance to ISO 14397-1 (2007) Sections 1 thru 6, which requires 2% verification between calculations and testing.
(Rigid Tire) Compliance to ISO 14397-1 (2007) Sections 1 thru 5.
