A T T A C H M E N T S

LEHE7416-00

Sub-Base Fuel Tank (Dual Wall)

Required Base and Tank Extensions Feature Code

Fuel Capacity

Feature

Extension

Weather Protective

Sound

Liters

Gallon

Code

Type

Industrial

Residential

Critical

Attenuated

Base Ext

EXTEN04

EXTEN07

2274

600

FTBDW26

Tank Ext

EXTEN03

Base Ext

EXTEN04

EXTEN07

2501

660

FTBDW28

Tank Ext

EXTEN03

Base Ext

EXTEN04

EXTEN07

2653

700

FTBDW30

Tank Ext

EXTEN03

Base Ext

EXTEN04

EXTEN07

3032

800

FTBDW32

Tank Ext

EXTEN03

Base Ext

EXTEN04

EXTEN07

3790

1,000

FTBDW34

Tank Ext

EXTEN01

Base Ext

EXTEN04

EXTEN07

4738

1,250

FTBDW36

Tank Ext

EXTEN01

Base Ext

EXTEN04

EXTEN07

5685

1,500

FTBDW38

Tank Ext

EXTEN01

Base Ext

EXTEN04

EXTEN07

6633

1,750

FTBDW40

Tank Ext

EXTEN01

Base Ext

EXTEN04

EXTEN07

7580

2,000

FTBDW42

Tank Ext

EXTEN01

Note: When ordered with an enclosure, the assembled package height (including 8-10 in. shipping skid) may exceed normal road

restriction heights. Customer is responsible for arranging shipment and obtaining all permits for potentially oversized load.

FACTORY INSTALLED FUEL TANKS

Sub-Base Fuel Tank (Dual Wall)

Required Tank Extensions

Fuel Capacity

Feature

Weather Protective

Sound

Liters

Gallon

Code

Industrial

Residential

Critical

Attenuated

2274

600

FTBDW3C

EXTEN03

2501

660

FTBDW47

EXTEN03

2653

700

FTBDW3D

EXTEN03

3032

800

FTBDW3E

EXTEN03

3790

1,000

FTBDW34

EXTEN01

4738

1,250

FTBDW36

EXTEN01

5685

1,500

FTBDW38

EXTEN01

6633

1,750

FTBDW40

EXTEN01

7580

2,000

FTBDW42

EXTEN01

*Refer back to Factory Installed Chart – Integral Fuel Tank Bases.

OPTIONAL SHIPPED LOOSE FUEL TANKS
