Document Number: 94392
For technical questions within your region, please contact one of the following:
www.vishay.com
Revision: 17-Sep-10
,
,
1
Phase Control Thyristors (Stud Version), 80 A
80RIA...PbF, 81RIA...PbF, 82RIA...PbF Series
Vishay Semiconductors
FEATURES
• Hermetic glass-metal seal
• International standard case TO-209AC (TO-94)
• Compliant to RoHS directive 2002/95/EC
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• DC motor controls
• Controlled DC power supplies
• AC controllers
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
80 A
TO-209AC (TO-94)
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST
CONDITIONS
VALUES
UNITS
I
T(AV)
80
A
T
C
85
°C
I
T(RMS)
125
A
I
TSM
50 Hz
1900
60 Hz
1990
I
2
t
50 Hz
18
kA
2
s
60 Hz
16
V
DRM
/V
RRM
400 to 1200
V
t
q
Typical
110
μs
T
J
- 40 to 125
°C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM
/V
RRM
, MAXIMUM
REPETITIVE PEAK AND
OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK VOLTAGE
V
I
DRM
/I
RRM
MAXIMUM
AT T
J
= 125 °C
mA
80RIA
81RIA
40
400
500
15
80
800
900
120
1200
1300
