Page 2
www.vishay.com
For technical questions, contact: [email protected]
Document Number: 94017
2
Revision: 07-Apr-08
30EPH03PbF
Vishay High Power Products
Ultrafast Rectifier,
30 A FRED Pt
TM
DYNAMIC RECOVERY CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Reverse recovery time
t
rr
I
F
= 1.0 A, dI
F
/dt = 50 A/µs, V
R
= 30 V
-
-
55
ns
T
J
= 25 °C
I
F
= 30 A
dI
F
/dt = - 200 A/µs
V
R
= 200 V
-
38
-
T
J
= 125 °C
-
52
-
Peak recovery current
I
RRM
T
J
= 25 °C
-
2.8
-
A
T
J
= 125 °C
-
7.3
-
Reverse recovery charge
Q
rr
T
J
= 25 °C
-
53
-
nC
T
J
= 125 °C
-
190
-
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Maximum junction and
storage temperature range
T
J
, T
Stg
- 65
-
175
°C
Thermal resistance,
junction to case per leg
R
thJC
-
0.5
0.9
°C/W
Thermal resistance,
junction to ambient
R
thJA
Typical socket mount
-
-
40
Thermal resistance,
case to heatsink
R
thCS
Mounting surface, flat, smooth
and greased
-
0.4
-
Weight
-
6.0
-
g
-
0.22
-
oz.
Mounting torque
6.0
(5.0)
-
12
(10)
kgf · cm
(lbf
⋅ in)
Marking device
Case style TO-247AC modified
30EPH03
