www.vishay.com For technical questions, contact: [email protected] Document Number: 94033
2 Revision: 21-May-08
8ETX06SPbF/8ETX06-1PbF
Vishay High Power Products Hyperfast Rectifier,
8 A FRED Pt TM
DYNAMIC RECOVERY CHARACTERISTICS (T
C
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time t
rr
I
F
= 1 A, dI
F
/dt = 100 A/µs, V
R
= 30 V - 15 19
ns
I
F
= 8 A, dI
F
/dt = 100 A/µs, V
R
= 30 V - 16 24
T
J
= 25 °C
I
F
= 8 A
dI
F
/dt = 200 A/µs
V
R
= 390 V
- 17 -
T
J
= 125 °C - 40 -
Peak recovery current I
RRM
T
J
= 25 °C - 2.3 -
A
T
J
= 125 °C - 4.5 -
Reverse recovery charge Q
rr
T
J
= 25 °C - 20 -
nC
T
J
= 125 °C - 100 -
Reverse recovery time t
rr
T
J
= 125 °C
I
F
= 8 A
dI
F
/dt = 600 A/µs
V
R
= 390 V
- 31 - ns
Peak recovery current I
RRM
- 12 - A
Reverse recovery charge Q
rr
- 195 - nC
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Maximum junction and storage
temperature range
T
J
, T
Stg
- 65 - 175 °C
Thermal resistance,
junction to case per leg
R
thJC
- 1.4 2
°C/W
Thermal resistance,
junction to ambient per leg
R
thJA
Typical socket mount - - 70
Thermal resistance,
case to heatsink
R
thCS
Mounting surface, flat, smooth and
greased
- 0.5 -
Weight
- 2.0 - g
- 0.07 - oz.
Mounting torque
6.0
(5.0)
-
12
(10)
kgf · cm
(lbf · in)
Marking device
Case style D 2 PAK 8ETX06S
Case style TO-262 8ETX06-1
