15ETX06SPbF/15ETX06-1PbF
Vishay High Power Products Hyperfast Rectifier,
15 A FRED Pt TM
DYNAMIC RECOVERY CHARACTERISTICS (T
C
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time t
rr
I
F
= 1 A, dI
F
/dt = 100 A/µs, V
R
= 30 V - 18 22
ns
I
F
= 15 A, dI
F
/dt = 100 A/µs, V
R
= 30 V - 20 32
T
J
= 25 °C
I
F
= 15 A
dI
F
/dt = 200 A/µs
V
R
= 390 V
- 22 -
T
J
= 125 °C - 52 -
Peak recovery current I
RRM
T
J
= 25 °C - 2.4 -
A
T
J
= 125 °C - 5.1 -
Reverse recovery charge Q
rr
T
J
= 25 °C - 25 -
nC
T
J
= 125 °C - 150 -
Reverse recovery time t
rr
T
J
= 125 °C
I
F
= 15 A
dI
F
/dt = 800 A/µs
V
R
= 390 V
- 37 - ns
Peak recovery current I
RRM
- 16 - A
Reverse recovery charge Q
rr
- 350 - nC
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Maximum junction and storage
temperature range
T
J
, T
Stg
- 65 - 175 °C
Thermal resistance,
junction to case per leg
R
thJC
- 1.0 1.3
°C/W
Thermal resistance,
junction to ambient per leg
R
thJA
Typical socket mount - - 70
Thermal resistance,
case to heatsink
R
thCS
Mounting surface, flat, smooth
and greased
- 0.5 -
Weight
- 2.0 - g
- 0.07 - oz.
Mounting torque
6.0
(5.0)
-
12
(10)
kgf · cm
(lbf · in)
Marking device
Case style D 2 PAK 15ETX06S
Case style TO-262 15ETX06-1
