60EPU02PbF/60APU02PbF
Vishay High Power Products
Ultrafast Soft Recovery Diode,
60 A FRED Pt
TM
DYNAMIC RECOVERY CHARACTERISTICS (T
C
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Reverse recovery time
t
rr
I
F
= 1.0 A, dI
F
/dt = 200 A/µs, V
R
= 30 V
-
-
35
ns
T
J
= 25 °C
I
F
= 60 A
dI
F
/dt = 200 A/µs
V
R
= 160 V
-
28
-
T
J
= 125 °C
-
50
-
Peak recovery current
I
RRM
T
J
= 25 °C
-
4
-
A
T
J
= 125 °C
-
8
-
Reverse recovery charge
Q
rr
T
J
= 25 °C
-
59
-
nC
T
J
= 125 °C
-
220
-
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Thermal resistance,
junction to case
R
thJC
-
-
0.70
K/W
Thermal resistance,
case to heatsink
R
thCS
Mounting surface, flat, smooth
and greased
-
0.2
-
Weight
-
5.5
-
g
-
0.2
-
oz.
Mounting torque
-
-
1.2
N
⋅ m
Marking device
Case style TO-247AC modified
60EPU02
Case style TO-247AC
60APU02
