Xfmr, Al176ulb, Fig. 1 – Altronix AL176UL Installation Instructions User Manual

Page 3

background image

3

ALTRONIX CORP.

BROOKLYN, NY 11220

MADE IN U.S.A.

AL176ULB

12VDC = JUMPER OUT
24VDC = JUMPER IN

VR1

AC ON

XFMR INPUT

+ BAT ----

+ DC OUT ----

AC FAIL

NO C NC

LOW BAT

NO C NC

DC ON

XFMR

Black Lead

White Lead

115 VAC input

60 Hz,

.6 amp

Green

Lead

(ground)

Stand-by

Battery

(optional)

Devices

or Load

Trouble

Supervision

Fig. 1
