AL100UL - 3 -
Terminal Identification:
Terminal Function/Description
Legend
AC/AC Low voltage AC input (16.5VAC/20VA). UL Listed. Class 2 plug-in transformer.
– DC + 12VDC @ .75 amp continuous power limited output.
– BAT + Stand-by battery connections. Maximum charge rate 500mA.
AC FAIL Indicates loss of AC, e.g connect audible device or alarm panel. Relay is normally
NC, C, NO energized when AC power is present. Contact rating 1 amp @ 28VDC.
LOW BAT Indicates low battery condition e.g connect audible device or alarm panel. Relay is
NC, C, NO normally energized. Contact rating 1 amp @ 28VDC.
