Bottom top right left – Altronix ALTV615DCUL Installation Instructions User Manual

Page 7

background image

5.10"

6.5625"

3.25"

3.25"

5.10"

5.10"

3.25"

1.00"

10.50"

1.00"

1.00"

1.00"

1.40"

1.20"

1.40"

1.20"

0.75"

0.75"

11.00"

12.50"

3.25"

0.9375"

0.9375"

1.40"

4.85"

4.85"

1.40"

1.20"

Bottom

Top

Right

Left

- 7 -

Enclosure Dimensions for:

• ALTV615DC44ULM

• ALTV615DC44ULCBM

• ALTV615DC48ULM

• ALTV615DC48ULCBM

• ALTV615DC416ULCBM

8.5"H x 7.5"W x 3.5"D

Enclosure Dimensions for:

• ALTV615DC416UL

• ALTV615DC416ULCB

• ALTV615DC616UL

• ALTV615DC616ULCB

13"H x 13.5"W x 3.25"D
