Overview:
These Altronix DC CCTV Power Supplies provide 6-15VDC distributed via fuse or PTC protected outputs for powering
CCTV Cameras, heaters and other video accessories.
ALTV615DCUL Reference Chart:
ALTV615DC44ULM 4 amp 6-15VDC 4 - x x 3.5 amp 0.9 amp
ALTV615DC44ULCBM 4 amp 6-15VDC 4 x x - 2.5 amp 0.9 amp
ALTV615DC48ULM 4 amp 6-15VDC 8 - x x 3.5 amp 0.9 amp
ALTV615DC48ULCBM 4 amp 6-15VDC 8 x x - 2.5 amp 0.9 amp
ALTV615DC416UL 4 amp 6-15VDC 16 - x x 3.5 amp 0.9 amp
ALTV615DC416ULCB 4 amp 6-15VDC 16 x x - 2.5 amp 0.9 amp
ALTV615DC616UL 6 amp 6-15VDC 16 - - x 3.5 amp 1.5 amp
ALTV615DC616ULCB 6 amp 6-15VDC 16 x x - 2.5 amp 1.5 amp
ALTV615DC416ULCBM* 4 amp 6-15VDC 16 x x - 2.5 amp 0.9 amp
* Same except for enclosure size.
Specifications:
Caution: This installation should be made by qualified service personnel and should conform to all local
codes and in accordance with the National Electrical Code.
Installation Instructions:
1. Mount unit in desired location.
2. Remove Power Distribution Module and isolation barrier (models with “M” suffix only).
3. Connect AC power to the two black and two white flying leads of the transformer (Figs. 1-4, pgs. 4-6).
Units with linecord installed skip Instruction #3.
Use 18 AWG or larger for all power connections. Connect green ground lead to earth ground (Fig. 1-4, pgs. 4-6).
Keep power limited wiring separate from non-power limited wiring. Minimum .25” spacing must be provided.
Use separate knockouts.
4. Adjust output voltage (unit is factory set at 12VDC): use the trimpot on the power supply board
prior to connecting CCTV devices.
5. Measure output voltage before connecting devices. This helps avoid potential damage.
CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting the
output voltage.
6. Reinstall isolation barrier and Power Distribution Module (models with “M” suffix only).
Altronix
Model Number
Output
Cur
rent
(max per output)
Total Output Cur
rent
(P
ow
er)
Output
V
oltage
115V
A
C
50/60Hz Input Cur
rent
PTC Protected Outputs Fuse Protected Outputs
- 2 -
Number
of
Outputs Class 2 Rated Po
w
er Limited
• UL Listed for Commercial CCTV Equipment (UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98, Audio,
Video and Similar Equipment.
• Four (4), eight (8), or sixteen (16) individual outputs.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
• Unit maintains camera synchronization.
• Ease of installation saves time & eliminates costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions:
ALTV615DC44ULM, ALTV615DC44ULCBM,
ALTV615DC48ULM, ALTV615DC48ULCBM, and
ALTV615DC416ULCBM: 8.5”H x 7.5”W x 3.75”D
All other models: 13”H x 13.5”W x 3.25”D
