Overview:
The AL175ULX is a power limited power supply/charger that will convert 115VAC / 60Hz input, into two individually
PTC protected 12VDC or 24VDC outputs, (see specifications). It is intended for use in applications requiring UL Listing
for Access Control System Units (UL 294) and applications requiring an interface with Fire Alarm Control Panels.
Specifications:
Power Supply Output Specifications:
Output VDC Switch Position Max. Stand-by Load DC Max. Alarm Load DC Battery (optional)
12VDC SW1 Open 1.75 amp 1.75 amp 12VDC
24VDC SW1 Closed 1.75 amp 1.75 amp 24VDC
Stand-by Specifications:
Output 4 hr. of Stand-by &
5 Minutes of Alarm
12VDC / 7 AH Battery Stand-by = 1.25 amp
24VDC / 7 AH Battery Alarm = 1.25 amp
Installation Instructions:
The AL175ULX should be installed in accordance with article 760 of The National Electrical Code or NFPA 72 as well
as all applicable Local Codes.
See Terminal Identification Chart on page 3 for a description of each terminal function.
1. Mount the AL175ULX in desired location.
2. Connect AC power to the black and white flying leads of the transformer. Secure green wire lead to earth ground.
Use 18 AWG or larger for all power connections (Battery, DC output). Use 22 AWG to 18 AWG for power
limited circuits (trigger inputs, dry outputs).
Keep power limited wiring separate from non-power limited wiring (115VAC / 60Hz Input, Battery Wires).
Minimum .25” spacing must be provided.
3. Set the AL175ULX to the desired DC output voltage by setting switch SW1 to the appropriate position
(refer to Power Supply Output Specification Table).
Agency Listings:
• UL Listed for Access Control Systems (UL294).
CUL Listed - CSA Standard C22.2
No.205-M1983, Signal Equipment.
• MEA - NYC Dept. of Buildings Approved.
• CSFM - California State Fire Marshal Approved.
• Conforms to NFPA 101 life safety codes
.
Input:
• Input 115VAC / 60 Hz, .6 amp.
Output:
• Selectable 12VDC or 24VDC power limited outputs.
• Class 2 Rated power limited outputs.
• 1.75 amp continuous supply current
@ 12VDC or 24VDC.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
Battery Backup:
• Maximum charge current: 400mA.
• Automatic switch over to stand-by battery when
AC fails.
Supervision:
• AC fail supervision (form "C" contacts).
• Dry trigger output (form "C" contacts).
Fire Alarm Interface:
• Dry trigger input.
Visual Indicators:
• AC input and DC output LED indicators.
Added Features:
• Includes power supply, transformer
and enclosure.
Enclosure Dimensions:
13”H x 13.5”W x 3.25”D
Product Weight:
8.9 lbs.
AL175ULX
Access Control Power Supply/Charger
Rev. L13Y7
