3
Door
Battery 1 Battery 2
Green
Lead
Battery connection (non power limited)
Wire
Strap
(from
Enclosure
to Door)
Black
Lead
White
Lead
115VAC input
60 Hz,
.6 amp
XFMR
Green
Lead
(ground)
ALTRONIX CORP. BROOKLYN, NY 11220
MADE IN U.S.A.
AL176ULB
12VDC = JUMPER OUT 24VDC = JUMPER IN
VR1
AC ON
XFMR INPUT
+ BAT
----
+ DC OUT
----
AC FAIL
NO C NC
LOWBAT NO C NC
DC ON
Fig. 1
