in the loss of output voltage. When the use of stand-by batteries are desired, they must be lead acid or gel type.
5. Connect appropriate signaling notification devices to AC Fail and Low Bat supervisory relay outputs.
Note: To meet UL requirements, AC Supervisory outputs must be connected to the zone of Alarm Control Panel or to
visual AC trouble indicator.
6. For Access Control Device connections refer to Terminal Identification Chart.
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions,
the DC output voltage should be checked for proper voltage level (Power Supply Output Specification Table).
Battery Test: Under normal load conditions check that the battery is fully charged, check specified
voltage both at battery terminal and at the board terminals marked [- BAT +] to insure there is no break in the battery
connection wires.
Note: Maximum charging current under discharge is 400mA.
Note: Expected battery life is 5 years, however it is recommended changing batteries in 4 years or less if needed.
LED Diagnostics:
Red (DC) Green (AC) Power Supply Status
ON ON Normal function
ON OFF Battery backup is powering output
OFF ON No DC output
OFF OFF Loss of AC. Discharged or missing stand-by battery. No DC output.
Terminal Identification:
Terminal Function/Description
Legend
XFMR INPUT Low voltage AC input (28VAC 56VA).
+ DC OUT --- Continuous positive (+) DC power output voltage. Common negative (-) output (ground).
+ BAT --- Stand-by battery connections.
AC FAIL Used to notify loss of AC e.g connect audible device or alarm panel. Relay is normally energized
N.O., C, N.C. when AC power is present. Contact rating 1 amp @ 28VDC.
LOW BAT Used to notify low battery condition e.g connect audible device or alarm panel. Relay is normally
N.O., C, N.C. energized. Contact rating 1 amp @ 28VDC.
