- 2 - ALTV1224DCseries
Overview:
The Altronix DC CCTV power supply is designed to power CCTV Cameras and accessories. It will provide 12VDC or
24VDC distributed via eight (8) or sixteen (16) fused or PTC protected outputs with a total of four (4) or six (6) amp
total continuous supply current.
Eight (8) or Sixteen (16) Output ALTV1224DC Reference Chart:
ALTV1224DC 4 amp 8 - x 3.5 amp 1.45 amp
ALTV1224DCCB 4 amp 8 x - 2.5 amp 1.45 amp
ALTV1224DC1 4 amp 16 - x 3.5 amp 1.45 amp
ALTV1224DC1CB 4 amp 16 x - 2.5 amp 1.45 amp
ALTV1224DC2 6 amp 16 - x 3.5 amp 2.5 amp
ALTV1224DC2CB 6 amp 16 x - 2.5 amp 2.5 amp
Specifications:
• AC input and DC output LED indicator. • Unit maintains camera synchronization.
• Filtered and electronically regulated outputs. • Ease of installation saves time and
• Power ON/OFF switch. eliminates costly labor.
• Spare fuses included. Enclosure Dimensions:
13.5"H x 13"W x 3.25"D
Installation Instructions:
1. Mount unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s
upper keyholes over the two upper screws, level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install the two fasteners. Place the enclosure’s upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 6).
Secure enclosure to earth ground.
2. Slide switch to OFF position (Fig. 1A, pg. 3, Fig. 2A, pg. 4 or Fig. 3A, pg. 5).
3. Set the unit to desired DC output voltage range by setting switch (SW1) on the power supply
board to the appropriate position (Fig. 1C, pg. 3, Fig. 2C, pg. 4 or Fig. 3C, pg. 5).
Use trimpot to adjust voltage if necessary (Fig. 1B, pg. 3, Fig. 2B, pg. 4 or Fig. 3B, pg. 5).
4. Connect the AC (115VAC 50/60 Hz) to the terminals marked L and N.
Connect earth ground to G terminal (Fig. 1, pg. 3, Fig. 2, pg. 4 or Fig. 3, pg. 5).
5. Measure output voltage before connecting devices. This helps avoid potential damage.
6. Connect each DC device to output terminals 1 through 8 (Fig. 1, pg. 3) or terminals 1 through 16 (Fig. 2, pg. 4 or
Fig. 3, pg. 5). Note: Be careful to observe camera polarity.
7. When batteries are being used the DC output voltage must be adjusted by turning the trim pot VR1
(Fig. 1B, pg. 3, Fig. 2B, pg. 4 or Fig. 3B, pg. 5) clockwise to increase the output voltage to 13.7VDC for 12VDC
operation and 27.1VDC for 24VDC operation.
Connect battery to terminals marked [-- BAT + ] (battery leads included) (Fig. 1, pg. 3, Fig. 2, pg. 4 or Fig. 3, pg. 5).
Use two (2) 12VDC batteries connected in series for 24VDC operation.
8. Slide switch to ON position (Fig. 1A, pg. 3, Fig. 2A, pg. 4 or Fig. 3A, pg. 5).
9. Green LED on the PD8/PD8CB or PD16W/PD16WCB board will illuminate when power is present.
10. Upon completion of wiring, secure enclosure door with screws (supplied).
Altronix
Model Number
Output
Cur
rent
(max per output) Total Output Cur
rent
(P
ow
er)
115V
A
C
50/60Hz Input
Cur
rent
Fuse Protected Outputs Number of OutputsPTC Protected Outputs
