See Terminal Identification Chart on page 2 for a description of each terminal function.
1. Install Power Supply Board into enclosure (Fig. 1 - Board Installation Diagram, pg. 3).
2. Mount the unit in desired location.
3. Power connections:
a. AL125UL, AL125ULX - Connect secondary (blue and yellow leads) from the transformer to the Power Supply
Board terminals marked [XFMR] (Fig. 1 - Board Installation Diagram, pg. 3). Connect 115VAC 50/60Hz to the
black and white flying leads of the transformer. Secure green wire lead to earth ground. Use 18 AWG or larger for
all power connections (Battery, AC input, DC outputs). Use 22 AWG to 18 AWG for power limited circuits
(Trigger inputs, Dry outputs, DC outputs).
b. AL125ULP, AL125ULE - Connect 24VAC from UL Listed 40VA plug-in transformer (included with AL125ULP)
to terminals marked [XFMR]. Keep power limited wiring separate from non-power limited wiring
(115VAC 50/60Hz Input, Battery Wires). Minimum .25” spacing must be provided.
4. Measure output voltage before connecting devices. This helps avoid potential damage.
5. Set the desired DC output voltage by setting switch SW2 to the appropriate position
(Power Supply Output Specifications Table, pg. 1).
6. Connect Fail-Safe locking devices to the terminals marked [COM-- and LOCK+]. Connect Fail-Secure locking
devices to the terminals marked [COM-- and STRIKE+] (Fig. 2 - Application Diagram, pg. 3).
7. Connect normally open access control device (i.e. cardreader, request to exit device, access control system) to the
terminals marked TRG INPUT [NO, GND] (Fig. 2 - Application Diagram, pg. 3).
8. Connect FACP interface to the terminals marked [FACP1 and FACP2]. Wire the 2.2K resistor (supplied) in series
for a normally closed input or in parallel for a normally open input (Fig. 2 - Application Diagram, pg. 3). If
required, set the latching FACP interface mode by closing SW1 (Fig. 2A - Application Diagram, pg. 3), and connect
a normally open reset device to the terminals marked RESET [NO, GND].
9. Connect battery to terminals marked [+ BAT -- ] (battery leads included). Use two (2) 12VDC batteries connected
in series for 24VDC operation.
Note: For Access Control applications, batteries are optional. When batteries are not used a loss of AC will result in the
loss of output voltage. When the use of stand-by batteries are desired, they must be lead acid or gel type.
10. Please insure that the cover is secured with the provided cam lock.
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper voltage level
(Power Supply Output Specifications Table, pg. 1).
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage both
at battery terminal and at the board terminals marked [- BAT +] to insure there is no break in the battery
connection wires.
Note: Maximum charging current under discharge is 400mA.
Note: Expected battery life is 5 years, however it is recommended changing batteries in 4 years or less if needed.
Terminal Identification:
Terminal Legend Function/Description
XFMR Low voltage transformer connections.
+ AUX -- Aux power output terminals. These terminals will supply 12VDC or 24VDC,
not affected by trigger, reset or fire alarm interface.
LOCK + Switched power output. Fail-Safe [LOCK+] supplies positive power when unit is not triggered
STRIKE + and FACP interface is inactive. Fail-Secure [STRIKE+] supplies positive power when unit
COM -- is triggered and/or fire alarm interface is activated. [COM-- ] supplies negative power.
FACP1 Supervised by 2.2K end of line resistor FACP interface. Short or open will cause power to be
FACP2 dropped to terminal marked [LOCK+] and supply power to terminal marked [STRIKE+].
Condition can be maintained even after restoration of the circuit (latching mode).
TRG INPUT Short between these two terminals will cause power to be dropped to terminal marked
NO, GND [LOCK+] and supplied to terminal marked [STRIKE+].
RESET Momentary short between these terminals would end latching FACP interface condition
NO, GND Feature active only if latching FACP is selected (SW1 closed).
-- BAT + Stand-by battery connections.
