- 2 -
ALTV2416UL3series
Overview:
These Altronix CCTV Power Supplies provide 24VAC/28VAC distributed via sixteen (16) fuse or PTC protected out-
puts for powering CCTV Cameras, heaters and other video accessories.
Sixteen (16) Output ALTV2416UL3 Series Reference Chart:
Altronix
Model Number
Output
Voltage
Total
Output
Current
(Power)
Number
of
Outputs
PTC
Protected
Outputs
(Class
2
power
limited
for
Dry
locations).
(Class
3
for
Wet
loca
-
tions).
Fuse
Protected
Class
1
Outputs
Individual
Output
Current
(max.
per
output
not
to
exceed
total
output
current).
Fuse
Rating
s
Main
Fuse
Ratings
Primary
In-line
Fuse
Rating
s
115VAC
60Hz
Input
Current
Agency
Listing
s
ALTV2416ULX3
24VAC
7 amp
16
------
Yes
3.5 amp
3.5
amp
5A/
250V
3.5A/
250V
1.8
amp
28VAC
6 amp
ALTV2416ULCBX3
24VAC
7 amp
16
Yes
------
2.5 amp
------
5A/
250V
3.5A/
250V
1.8
amp
28VAC
6 amp
ALTV2416300UL
24VAC
12.5 amp
16
------
Yes
3.5 amp
3.5
amp
15A/
32V
------
2.7
amp
28VAC
10 amp
ALTV2416300ULCB3
24VAC
12.5 amp
16
Yes
------
2.5 amp
------
15A/
32V
------
2.7
amp
28VAC
10 amp
ALTV2416300ULM3
24VAC
12.5 amp
16
------
Yes
3.5 amp
3.5
amp
------
2.7
amp
28VAC
10 amp
ALTV2416300ULCBM3
24VAC
12.5 amp
16
Yes
------
2.5 amp
------
------
------
2.7
amp
28VAC
10 amp
ALTV2416600UL3
24VAC
25 amp
16
------
Yes
3.5 amp
3.5
amp
15A/
32V
------
5.4
amp
28VAC
20 amp
ALTV2416600ULCB3
24VAC
25 amp
16
Yes
------
2.5 amp
------
15A/
32V
------
5.4
amp
28VAC
20 amp
Specifications:
Installation Instructions:
1. Mount unit in desired location.
2. Set power switch on power distribution board marked [PD] to OFF position for models ALTV2416ULX3 or
ALTV2416ULCBX3 (Figs. 1, 2, pgs. 4, 5). Set power disconnect circuit breaker to OFF position for all
other models (Figs. 3a-8a, pgs. 6-10).
3. All units are factory set for 24VAC operation.
For 28VAC operation, adjust unit prior to mounting and applying power as follows:
Change the wire position so that the wire marked [28V] is connected to the terminal marked [P] and
the wire marked [24V] is connected to the terminal marked [S].
Note: ALTV2416ULCBX3 set for 28VAC operation is not Class 2 Rated, not power limited.
• UL Listed for Commercial CCTV Equipment (UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98, Audio,
Video and Similar Equipment.
• Surge suppression.
• AC power LED indicator.
• Power ON/OFF switch
(ALTV2416ULX3, ALTV2416ULCBX3).
• Illuminated power disconnect circuit breaker
with manual reset (all other models).
• Unit maintains camera synchronization.
• Ease of installation saves time & eliminates costly labor.
• Spare fuses included (on fuse protected models).
• Factory installed 3-wire line cord.
Enclosure Dimensions:
ALTV2416300ULM3 and ALTV2416300ULCBM3:
8.5”H x 7.5”W x 3.5”D
ALTV2416ULX3, ALTV2416ULCBX3,
ALTV2416300UL3, ALTV2416300ULCB3,
ALTV2416600UL and ALTV2416600ULCB3:
13.5”H x 13”W x 3.25”D
