Altronix ALTV2416ULX3 Installation Instructions User Manual
Cctv power supplies installation guide

ALTV2416UL3 Series
CCTV Power Supplies
Installation Guide
Models Include:
•
ALTV2416ULX3
•
ALTV2416ULCBX3
- 24VAC @ 7 amp (170VA)
- 24VAC @ 7 amp (170VA)
or 28VAC @ 6 amp (170VA).
or 28VAC @ 6 amp (170VA).
- Sixteen (16) Fuse Protected Outputs.
- Sixteen (16) PTC Protected Outputs.
- Factory installed 3-wire linecord.
- Factory installed 3-wire linecord.
•
ALTV2416300UL3
•
ALTV2416300ULCB3
- 24VAC @ 12.5 amp (300VA)
- 24VAC @ 12.5 amp (300VA)
or 28VAC @ 10 amp (280VA).
or 28VAC @ 10 amp (280VA).
- Sixteen (16) Fuse Protected Outputs.
- Sixteen (16) PTC Protected Outputs.
- Factory installed 3-wire linecord.
- Factory installed 3-wire linecord.
•
ALTV2416300ULM3
•
ALTV2416300ULCBM3
- 24VAC @ 12.5 amp (300VA)
- 24VAC @ 12.5 amp (300VA)
or 28VAC @ 10 amp (280VA).
or 28VAC @ 10 amp (280VA).
- Sixteen (16) Fuse Protected Outputs.
- Sixteen (16) PTC Protected Outputs.
- Factory installed 3-wire linecord.
- Factory installed 3-wire linecord.
•
ALTV2416600UL3
•
ALTV2416600ULCB3
- 24VAC @ 25 amp (600VA)
- 24VAC @ 25 amp (600VA)
or 28VAC @ 20 amp (560VA).
or 28VAC @ 20 amp (560VA).
- Sixteen (16) Fuse Protected Outputs.
- Sixteen (16) PTC Protected Outputs.
- Factory installed 3-wire linecord.
- Factory installed 3-wire linecord.
Rev. 040506
