AL1012ULXseries - 5 -
N
COMMO N POWER OU TPU TS
P
FU SED P OWER OU TPUTS
D1
INPUT
R1 LED
3.5A 250V 3.5A 250V 3.5A 250V
1 2
DC Output to devices
(non-power limited)
Green
Lead
Battery connection (non-power limited)
Door
Wire Strap
(from
Enclosure
to Door)
115 power
mains
(non-power
limited)
Divider
CAUTION: De-energize unit prior to servicing. For continued protection
against risk of electric shock and fire hazard replace fuse with the same type
and rating 3.5A, 250V. Replace fuse cover before energizing.
Class 1
Provide 1/4" separation between
power limited and all other circuits
Battery and AC
Supervision Circuit
(power limited)
Use separate knockout
Non-power limited
+
D
C
--
-
BAT FAIL NC C NO NC C NO
+
B A
T
--
-
DC
AC FAIL L G N
AC
3 .5
A 2 5 0 V
Green Lead
Keep power limited wiring separate from non-power limited. Use minimum .25" spacing.
12VDC Rechargeable Battery
(optional)
Fig. 1
